36 Chapter 2: Hardware Setup
5. Follow steps 1 to 4 to install the
other rail.
6. Insert the rails to the holes on
the front panel and match the
68-pin connector at the rear of
the combo box with the
connector on the front panel.
7. Firmly push the combo box into
the chassis until it fits in place.
In case you need to replace either the CD-ROM or the floppy drive
inside the combo box, follow these steps.
1. Use a Philips (cross)
screwdriver to remove the
screws the secure the drives to
the combo box.
2. To remove the CD-ROM drive,
insert the end of the
screwdriver into the upper hole
on the side of the combo box
and lightly push the drive
toward the front. The drive slips
out for about an inch. Pull the
drive out of the combo box.
3. To remove the floppy drive, insert the end of the screwdriver into
the lower hole on the side of the combo box and lightly push the
drive toward the front. When the drive slips out, pull it out.
