ASUS DSAN-DX 4-25
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Power
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
TD configuration
mode setting
4.6.4 Hardware Monitor
Hardware Monitor
CPU1 :N/A
CPU2 :33ºC/91ºF
System1 :38ºC/102ºF
System2 :35ºC/95ºF
CPU Fan1 :N/A
CPU Fan2 :1713 RPM
FRN FAN1 :N/A
FRN FAN2 :N/A
FRN FAN3 :N/A
FRN FAN4 :N/A
REAR FAN1 :N/A
REAR FAN2 :N/A
FAN Control Mode [SmartFan II Mode]
CPU1 TargetTemp Value [ 55]
CPU1 TargetTemp Value [ 55]
System1 TargetTemp Value [ 55]
System2 TargetTemp Value [ 55]
CPU1/CPU2 [xxxºC/xxxºF]
System1/2 [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the motherboard
and CPU temperatures. Select [Ignored] if you do not wish to display the detected
temperatures. The CPU2 Temperature shows N/A if no processor is installed in
CPU2 socket.
CPU FAN1/2; FRN FAN1/2/3/4; REAR FAN1/2 [xxxxRPM] or [N/A]
The onboard hardware monitor automatically detects and displays the CPU, front,
and rear fan speed in rotations per minute (RPM). If the fan is not connected to the
motherboard, the field shows N/A.
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
VCOREA Voltage :0.096 V
VCOREB Voltage :1.328 V
Vtt Voltage :1.216 V
VSEN1 :1.504 V
VSEN2 :1.792 V
3VSEN :3.328 V
12VSEN :12.288 V
5VDD :4.920 V
5VSB :4.944 V
VBAT :3.136 V
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Scroll down for more items.
