ASUS DSAN-DX 2-9
Internal connectors Page
1. Floppy disk drive connector (34-1 pin FLOPPY1) 2-30
2. Serial ATA connectors
(7-pin SATA1, SATA2, SATA3, SATA4, SATA5, SATA6)
2-30
3. IDE connector (40-1 pin PRI_IDE1 2-31
4. SAS connectors
(7-pin SAS1, SAS2, SAS3, SAS4, SAS5, SAS6, SAS7, SAS8)
2-32
5. Hard disk activity LED connector (4-pin HDLED1) 2-32
6. Serial General Purpose Input/Output connector (6-1 pin SGPIO1) 2-33
7. Serial General Purpose Input/Output connectors
(6-1 pin SGPIO2/3)
2-33
8. USB connectors (10-1 pin USB34, USB56) 2-34
9. CPU and system fan connectors (4-pin CPU_FAN1/2,
REAR_FAN1/2, FRNT_FAN1/2/3/4)
2-34
10. Serial port connectors (10-1 pin COM2) 2-35
11. Power supply SMBus connector (5-pin PSUSMB1) 2-35
12. SSI power connectors (24-pin ATXPWR1, 8-pin ATX12V1) 2-36
13. System panel connector (20-1 pin PANEL1) 2-37
14. Auxiliary panel connector (20-pin AUX_PANEL1) 2-38
