2-6 Chapter 2: BIOS information
2.4 Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other system
devices.
Take caution when changing the settings of the Advanced menu items. Incorrect field
values can cause the system to malfunction.
CPU Configuration
JumperFree Configuration
Chipset
Onboard Devices Configuration
USB Configuration
PCIPnP
Configure CPU.
BIOS SETUP UTILITY
Main Advanced Power Boot Tools Exit
2.3.4 Storage Configuration
The items in this menu allow you to set or change the configurations for the SATA devices
installed in the system. Select an item then press if you want to configure the item.
OnChip S-ATA Controller [Enabled]
Enables or disables the OnChip SATA controller. Configuration options: [Disabled] [Enabled]
SATA Mode Select [SATA Mode]
This item appears only when you set the OnChip SATA Controller item to [Enabled]. Allows
you to set the OnChip SATA mode. Configuration options: [SATA Mode] [RAID Mode] [AHCI
Mode]
Hard Disk Write Protect [Disabled]
Disables or enables device write protection. This will be effective only if device is accessed
through BIOS. Configuration option: [Disabled] [Enabled]
IDE Detect Time Out (Sec) [5]
Selects the time out value for detecting ATA/ATAPI devices.
Configuration options: [0] [5] [10] [15] [20] [25] [30] [35]
2.3.5 System Information
This menu gives you an overview of the general system specifications. The BIOS
automatically detects the items in this menu.
BIOS Information
Displays the auto-detected BIOS information.
Processor
Displays the auto-detected CPU specification.
System Memory
Displays the auto-detected system memory.
