2-19 ASUS V-series M4A3000E
The smaller icons on the right side of the LaunchBar are:
Displays your Express Gate version.
Launches the help file.
Launches the Configuration Panel which allows you to specify network
settings and other settings.
Configures the network.
Adjusts the volume.
This icon appears only when a removable storage device / USB drive is
connected. Left-click this icon to launch the File.Manager window. Right-
click it to eject the removable storage device / USB drive.
Exits ASUS Express Gate. Click Yes to enter the operating system you
installed on the hard disk drive.
Powers off the computer.
Accessing.the.Internet
To configure the network settings:
1. Click Configuration Panel on
the LaunchBar.
2. Click Network.
3. Make the proper network
configurations. Each network interface
is enabled immediately after you tick
the Enable checkbox.
The number of the LAN ports vary with the motherboard.
