Asus P8H61-M2/TPM/SI User Manual
Page 16

ASUS P8H61-M2 Series
1-6
• For better performance of memory, we recommend that you use the blue slots first.
• Visit the ASUS website at www.asus.com for the latest QVL.
SS: Single-sided / DS: Double-sided
DIMM support:
• A*: Supports one module inserted into any slot as Single-channel memory configuration.
• B*: Supports one pair of modules inserted into either the blue slots or the black slots as
one pair of dual-channel memory configuration.
• C*: Supports two pairs of modules inserted into both the blue slots and the black slots as
two pairs of dual-channel memory configuration.
DIMM_A1
DIMM_A2
DIMM_B1
DIMM-B2
1
SS
2
SS
3
SS
SS
4
DS
5
DS
6
DS
DS
7
SS
SS
SS
SS
SS: Single -sided
DS: Double-sided
The following table shows the way to use DIMM slots:
