2-42 Chapter 2: Hardware information
Chapter 2
2.3.10 Rear panel connection
Rear panel connectors
1. PS/2 mouse port 9. Optical S/PDIF Out port
2. Coaxial S/PDIF Out port 10. External SATA port
3. USB 2.0 ports 5 and 6 11. Power External SATA port
4. Bluetooth module* 12. IEEE 1394a port
5. USB 2.0 ports 3 and 4 13. USB 2.0 ports 1 and 2
6. Realtek ® LAN (RJ-45) port ** 14. USB 3.0 ports 1 and 2
7. Intel ® LAN (RJ-45) port **
(Recommended for single LAN usage) 15. Clear CMOS switch
8. PS/2 keyboard port 16. Audio I/O ports***
*, **and ***: Refer to the tables on the next page for bluetooth module LED, LAN port LED, and
audio port definitions.
