Removing the cover, Removing the front panel assembly – Asus P3-PE5 User Manual
Page 4
4
Quick Installation Guide
Quick Installation Guide
English
3. Pull the cover.
Removing the cover
1. Locate two cover screws.
2. Remove the cover screws.
4. Lift the cover, then set aside.
Removing the front panel assembly
1. Locate the front panel
assembly hooks.
2. Pull the hooks outward to
remove.
5. Lift the expansion card lock to
a 90º-100º angle.
6. Lift the chassis support
bracket, then remove.
