18

2

Knowing the Parts

Bottom Side

Refer to the diagram below to identify the components on this side of the Notebook PC. Details are
given starting from the top and going clockwise.

IMPORTANT! The bottom of the Notebook PC can get very hot. Be careful when han-
dling the Notebook PC while it is in operation or recently been in operation. High
temperatures are normal during charging or operation. DO NOT PUT THE NOTEBOOK
PC ON THE LAP OR OTHER PARTS OF THE BODY TO AVOID INJURY FROM THE HEAT.

Battery Pack

Battery Lock

Optical drive

Lock

Hard Disk Drive

Compartment

Memory

Compartment

CPU

Compartment

Cooling Fan

(Air Vents)

Shutdown

Button

Cooling Fan

Mini-PCI

Compartment
