9 ASUS V8200 Series User’s Manual
2. H/W Setup
Deluxe
2. Hardware Setup
ASUS V8200 Deluxe
DDR Frame Buf
fer
Stereo Glasses Output
Video Input (ASUS
Video) 7pin S compatib
le)
V
GA Output
S-Video Output Composite (RCA) Output
V
GA Monitor
output (15pin) (standard) VR Glasses Output composite/TV output (RCA) CCD/camcorder input/T
uner/
TV Bo
x Input
(7pin) SVHS/TV output (7pin)
Projector
ASUS TV
Bo
x
CA
TV
Composite (RCA) Input
S-Video to Composite Cab
le
3D Glasses (ASUS VR-100G)
®
123 123 NTSC
PA
L
JP1 JP1
Use the same
TV standard for all devices. For example,
if your
TV uses the NTSC standard, then you should set
JP1 to
“NTSC.
”
Digital
PC to
TV
Encoder
J1
Fa
n
Po
w
e
r
The VIP
(V
ideo Interface Port) Connector are used for third party add-on modules,
such as video capture cards or television tuners.
VGA BIOS
®
Digital V
ideo
Decoder
F
rame Buf
fer (DDR)
DDR: Double Data Rate
VIP
Connector
A
NVIDIA
TM
nFiniteFX
TM
GeForce3
TM
GPU
(Graphics Processing Unit)
Chip with Fan
Item Checklist
ASUS
AGP-V8200 Deluxe Graphics Card (P
AL
or NTSC)
ASUS
VR-100G
This User
’s Manual
ASUS
V8200 Series Driver & Utility CD Disc
Notes
•
Use the same
TV
standard for all devices.
•
and
cannot be connected at the same time.
