ix
CPU LGA775 Socket for Intel ® Core�2 Extreme /Core�2 Quad / Core�2 Extreme /Core�2 Quad / Core�2 Quad /
Core�2 Duo / Pentium ® dual-core /Celeron ® dual-core
processors
Supports Intel ® 45nm multi-core CPU
Intel ® Hyper-Threading Technology ready
Support Enhanced Intel SpeedStep Technology (EIST)
(Refer to www.asus.com for Intel ® CPU support list)
Chipset Northbridge: Intel ® P43
Southbridge: Intel ® ICH10R
System bus 1600(O.C)/1333/1066/800MHz
Memory Dual-channel memory architecture
- 4 x 240-pin DIMM sockets support unbuffered non-ECC
DDR3 1600 (O.C.)/1333/1066/800MHz memory modules
- Supports up to 16GB system memory
* It is recommended to install the memory modules into the orange
slots for better overclocking capability.
** When you install a total memory of 4GB capacity or more,
Windows ® 32-bit operating system may only recognize less
than 3GB. We recommend a maximum of 3GB system memory
if you are using a Windows ® 32-bit OS.
Expansion slots 1 x PCIe x16 slot
2 x PCIe x1 slots
3 x PCI slots
Storage Southbridge Intel ® ICH10R supports: 6 x Serial ATA 3Gb/s
supports RAID 0, 1, 0+1, AND 5
JMB361 supports:
- 1 x UltraDMA 133/100/66 connector
- 1 x eSATA port
LAN L1E Gb LAN controller
Audio ALC887 High Definition Audio 8-channel CODEC
- Supports Jack-detect and Multi-streaming
- Optical S/PDIF output
USB 12 x USB 2.0/1.1 ports (6 ports at mid-board, 6-ports at back panel)
ASUS exclusive
overclocking features
SFS (Stepless Frequency Selection):
- FSB tuning from 200MHz to 800MHz at 1MHz increment
Overclocking protection:
- ASUS C.P.R. (CPU Parameter Recall)
ASUS Special
features
ASUS CrashFree BIOS 3
ASUS EZ Flash2
ASUS EPU-4 Engine
ASUS Q-Fan
ASUS Turbo Key
ASUS AI NET2
ASUS MyLogo 2
ASUS Express Gate
P5P43TD PRO specifications summary
(continued on the next page)
