ASUS P4SE/U2 Motherboard

1-5

Standby power LED. This green LED lights up if there is a standby
power on the motherboard. The LED acts as a reminder to turn off
the system power before plugging or unplugging devices.

Flash ROM. This 2Mb firmware contains the programmable BIOS
program.

Audio CODEC. The CMedia 4-channel CODEC is an AC’97
compliant audio CODEC designed for PC multimedia systems.
(on audio models only)

PCI slots. These 32-bit PCI 2.2 expansion slots support bus
master PCI cards like SCSI and LAN cards with 133MB/s maximum
output.

LAN PHY. This SiS 962L integrated 10/100 Mbps Fast Ethernet
with Realtek external PHY supports your local area networking
needs.

PS/2 mouse port. This green 6-pin connector is for a PS/2 mouse.

RJ-45 port. This port allows connection to a Local Area Network
(LAN) through a network hub. (on LAN models only)

Parallel port. This 25-pin port connects a parallel printer, a
scanner, or other devices.

GAME/MIDI port. This connector supports a joystick or a game
pad for playing games, and MIDI devices for playing or editing
audio files.

Microphone jack. This Mic (pink) jack connects a microphone.

Line In jack. This Line In (light blue) jack connects a tape player or
other audio sources.

Line Out jack. This Line Out (lime) jack connects a headphone or
a speaker.

Serial ports. These ports connect to your serial mouse and other
serial devices.

USB ports. These two 4-pin Universal Serial Bus 2.0 (USB 2.0)
ports are available for connecting USB devices such as a mouse
and PDA.

PS/2 keyboard port. This purple 6-pin connector is for a PS/2
keyboard.
