ASUS P8H61-M PLUS 1-20
6. Intel ® H61 Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1~4)
These connectors connect to Serial ATA 3.0 Gb/s hard disk drives and optical drives via
Serial ATA 3.0 Gb/s signal cables.
• You must install Windows ® XP Service Pack 3 or later version before using Serial ATA
hard disk drives.
• When using hot-plug and NCQ, set the SATA Mode item in the BIOS to [AHCI Mode].
See section 2.5.4 SATA Configuration for details.
7. USB connectors (10-1 pin USB78, USB910)
These connectors are for USB 2.0 ports. Connect the USB module cable to any of
these connectors, then install the module to a slot opening at the back of the system
chassis. These USB connectors comply with USB 2.0 specification that supports up to
480 Mbps connection speed.
Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard!
The USB module cable is purchased separately.
GN
D
RSATA_TXP1 RSATA_TXN1
GN
D
RSATA_RXP1 RSATA_RXN1
GN
D
SATA3G_1 SATA3G_2
GN
D
RSATA_TXP2 RSATA_TXN2
GN
D
RSATA_RXP2 RSATA_RXN2
GN
D
GN
D
RSATA_RXN3 RSATA_RXP3 GN
D
RSATA_TXN3 RSATA_TXP3 GN
D
GN
D
RSATA_RXN4 RSATA_RXP4 GN
D
RSATA_TXN4 RSATA_TXP4 GN
D
SATA3G_3 SATA3G_4
P8H61-M PLUS
P8H61-M PLUS SATA connectors
P8H61-M PLUS
P8H61-M PLUS USB2.0 connectors
PIN 1
USB+5
V
USB_P10- USB_P10+ GND NC
USB+5
V
USB_P9
-
USB_P9
+
GND
USB910
PIN 1
USB+5
V
USB_P8
-
USB_P8
+
GND NC
USB+5
V
USB_P7
-
USB_P7
+
GND
USB78
