2-10 ASUS M4A78-AM
2.4.1 JumperFree Configuration
The following item appears only when the CPU Overclocking item is set to [Manual].
CPU/HT Reference Clock (MHz) [200]
Allows you to set the CPU/HT Reference Clock. The valid value is between 200 MHz
and 550 MHz.
The following item appears only when the CPU Overclocking item is set to [Overclock
Profile].
Overcloking Options [Auto]
Allows you to set the overclocking options. Configuration options: [Auto] [Overclock
2%] [Overclock 5%] [Overclock 8%] [Overclock 10%]
PCIE Overclocking [Auto]
Allows you to select the PCIE Overclocking. Configuration options: [Auto] [Manual]
The following item appears only when the PCIE Overclocking item is set to [Manual].
PCIE Clock [100]
Allows you to set the PCIE clock. The valid value is between 100 and 150.
Processor Frequency Multiplier [Auto]
Allows you to select the processor frequency. Configuration options: [Auto] [x8.0 1600 MHz]
[x8.5 1700 MHz] [x9.0 1800 MHz] [x9.5 1700 MHz] ... [x24.5 4900 MHz] [x25.0 5000 MHz]
CPU Over Voltage [Auto]
Allows you to select the CPU over voltage or set it to auto for safe mode.
Configuration options: [Auto] [Normal] [+ 50mv] [+ 100mv] [+150mv]
GPU Overclocking [Auto]
Allows you to select the GPU Overclocking. Configuration options: [Auto] [Manual]
The following item appears only when the GPU Overclocking item is set to [Manual].
GPU Engine Clock [500]
Allows you to set the GPU engine clock. The valid value is between 150 and 1000.
Depending on your AMD CPU type (AM2, AM2+ or AM3), the items on this section may not
exactly match what you see on your screen.
CPU Overclocking [Auto]
Allows selection of CPU overclocking options to achieve desired CPU internal frequency.
Select any of the preset overclocking.
• Manual - Allows you to individually set the overclocking parameters.
• Auto - Loads the optimal settings for the system.
• Overclock Profile - Loads overclocking profiles with optimal parameters for stability when
overclocking.
