3-8 Chapter 3: BIOS setup
Chapter 3
3.4 Main menu
When you enter the BIOS Setup program, the Main menu screen appears, giving you an
overview of the basic system information. You can set the system time and date, BIOS
language, and the type of floppy drive installed.
Refer to 3.3.1 BIOS menu screen for information on the menu screen items and how to
navigate through them.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Main Ai Tweaker Advanced Power Boot Tools Exit
System Time [10:55:25]
System Date [Tue 12/09/2008] 8]]
Language [English]
Primary IDE Master [Not Detected]
Primary IDE Slave [Not Detected]
SATA1 [HDT722516DLA380]
SATA2 [Not Detected] Not Detected]]
SATA3 [Not Detected]
SATA4 [Not Detected]
SATA5 [Not Detected]
SATA_E1 [Not Detected]
Storage Configuration
System Information System Information
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure the System
Time.
3.4.1 SATA 1-5; SATA_E1
While entering Setup, the BIOS automatically detects the presence of SATA devices. There
is a separate submenu for each SATA device. Select a device item then press to
display the SATA device information.
SATA_E1 menu displays the status of the hard disk connected to the SATA_E1 (ornage,
port 0) connector on the motherboard.
Primary IDE Master
Device : Hard Disk
Vendor : WDC WD800JD-00LSA0
Size : 80.0GB
LBA Mode : Supported
Block Mode : 16 Sectors
PIO Mode : 4
Async DMA : MultiWord DMA-2
Ultra DMA : Ultra DMA-5
SMART Monitoring: Supported
Type [Auto]
LBA/Large Mode [Auto]
Block(Multi-sector Transfer)M [Auto]
PIO Mode [Auto]
DMA Mode [Auto]
SMART Monitoring [Auto]
32Bit Data Transfer [Enabled]
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Main
Select the type of
device connected to
the system.
When using one hard disk in Normal Mode, connect the hard disk to the SATA_E1 (orange,
port 0) connector on the motherboard.
