Page 36

Chapter 2: Hardware setup

2-18

2.5.2

Replacing the riser card (optional)

You may replace the default riser card with the optional PCI Express x16 riser card

(x16 link).
To replace the default riser card:
1. Firmly hold the riser card bracket,

then pull it up to detach it from

the PCI Express x16 slot on the

motherboard.

2. Locate the two screws on the riser

card bracket, then remove the

screws from the bracket.

4. Secure the optional riser card to the

riser card bracket with two screws.

3. Take out the optional riser card

from its package and locate the two

screw holes on the card.
