xi
P5KC specifications summary
(continued on the next page)
CPU LGA775 socket for Intel ® Core ™ 2 Quad / Core ™ 2 Extreme
/ Core ™ 2 Duo / Pentium ® Extreme / Pentium ® D
/ Pentium ® 4 processors
Compatible with Intel ® 05A/05B/06 processors
Supports Intel ® next generation 45nm Multi-Core CPU
* Refer to www.asus.com for Intel ® CPU support list
Chipset Intel ® P35 / ICH9 with Intel ® Fast Memory Access
Technology
System bus 1333/1066/800 MHz
Memory Dual-channel memory architecture
- 2 x 240-pin DIMM sockets support up to
4 GB system memory unbuffered / non-ECC DDR3
1333/1066/800 MHz memory modules
- 4 x 240-pin DIMM sockets support up to
8 GB system memory unbuffered / non-ECC DDR2
1066 /800/667 MHz memory modules
Expansion slots 2 x PCI Express ™ x16 slots with CrossFire support
(blue @ x16 mode, black @ x4 or x1 mode)
1 x PCI Express ™ x1 slot
3 x PCI slots
Storage Southbridge
- 4 x Serial ATA 3.0 Gb/s ports
JMicron ® JMB363 PATA and SATA controller supports:
- 1 x UltraDMA 133/100/66 for up to 2 PATA devices
- 1 x Serial ATA 3.0 Gb/s port
- 1 x External SATA 3.0 Gb/s port (SATA On-the-Go)
- Supports SATA RAID 0, 1, and JBOD
LAN PCIe Gigabit LAN controller
High Definition audio Realtek ® 8-channel High-Definition Audio
CODEC
- Supports Jack-Sensing, Enumeration, and
Multi-Streaming Technology
- Coaxial/Optical S/PDIF out ports at back I/O
- ASUS Noise Filter
IEEE 1394 VIA VT6308P controller supports 2 x IEEE 1394a ports
(one at midboard; one at back panel)
USB Supports up to 12 USB 2.0 ports (6 at mid-board, 6 at
back panel)
