CHARACTERISTICS
6
components
Ref. Q.ty
Product components
1
1
Hood Body, complete with: Controls, Light,
Blower, Filters
2
1
Telescopic Chimney comprising:
2.1 1
Upper Section
2.2 1
Lower Section
9
1
Reducer Flange ø 150-120 mm
10 1
Damper ø 150
14.1 2
Air Outlet Connection Extension
15 1
Air Outlet Connection
Ref. Q.ty
Installation components
7.2.1 2
Upper Chimney Section Fixing Brackets
7.3 1
Air Outlet Connection Support
11 6
Wall Plugs
12a 6
Screws 4,2 x 44,4
12c 6
Screws 2,9 x 9,5
Q.ty
Documentation
1
Instruction Manual
���
�
��
��
����
�����
���
��
���
��
���
�
���
���
�
