Asus P5P800 - Manual (Page 25)

A S U S P 5 P 8 0 0 A S U S P 5 P 8 0 0 A S U S P 5 P 8 0 0 A S U S P 5 P 8 0 0 A S U S P 5 P 8 0 0 2 - 5 2 - 5 2 - 5 2 - 5 2 - 5
I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s P a g e P a g e P a g e P a g e P a g e
1. Floppy disk drive connector (34-1 pin FLOPPY) 2-23
2. Primary IDE connector (40-1 pin PRI_IDE) 2-23
4. Secondary IDE connector (40-1 pin SEC_IDE) 2-23
5. Serial ATA connectors (7-pin SATA1, SATA2) 2-24
7. CPU fan connector (4-pin CPU_FAN) 2-26
9. Chassis fan connector (3-pin CHA_FAN) 2-26
11. Serial port 2 connector (10-1 pin COM2) 2-27
12. USB headers (10-1 USB56, USB78) 2-27
13. ATX power connector (24-pin EATXPWR) 2-28
14. ATX 12V power connector (4-pin ATX12V) 2-28
15. Optical audio connector (4-pin CD) 2-29
15. Auxilliary audio connector (4-pin AUX) 2-29
16. GAME/MIDI connector (16-1 pin GAME) 2-29
17. Chassis intrusion connector (4-1 pin CHASSIS) 2-30
18. Front panel audio connector (10-1 pin FP_AUDIO) 2-30
19. System panel connectors (20-1 pin PANEL) 2-31
- System Power LED (Green 3-pin PLED)
- Hard Disk activity (Red 2-pin IDE_LED)
- System warning speaker (Orange 4-pin SPEAKER)
- Power/Soft-off button(Yellow 2-pin PWRSW)
- Reset switch (Blue 2-pin RESET)
