ASUS P8Z68-V/GEN3

2-3

Chapter 2

Layout contents

Connectors/Jumpers/Slots

Page

CPU, chassis, and power fan connectors (4-pin CPU�FAN

/CPU�FAN�OPT, 4-pin CHA�FAN1, 3-pin CHA�FAN2,

3-pin PWR�FAN1-2)

2-26

ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)

2-28

LGA1155 CPU socket

2-4

DDR3 DIMM slots

2-5

TPU switch

2-16

EPU switch

2-17

MemOK! switch

2-15

USB 3.0 connector (20-1 pin USB3�34)

2-23

Intel

Z68 Serial ATA 6.0 Gb/s connectors

(7-pin SATA6G�1/2 [gray])

2-21

10.

Intel

Z68 Serial ATA 3.0 Gb/s connectors

(7-pin SATA3G�3–6 [blue])

2-22

11.

Clear RTC RAM (3-pin CLRTC)

2-20

12.

System panel connector (20-8 pin PANEL)

2-29

13.

USB 2.0 connectors (10-1 pin USB78, USB910, USB1112)

2-24

14.

POWER-on switch

2-14

15.

Front panel audio connector (10-1 pin AAFP)

2-27

16.

Digital audio connector (4-1 pin SPDIF�OUT)

2-25
