1.3.3 Motherboard layout
H61M-PLUS
PCIEX16
PCIEX1_1
PCIEX1_2
F_PANEL
SPEAKER
CLRTC
KBPWR
USBPW1-4
USBPW5-10
USB78 USB910 USB56
AAFP
ATX12V
EATXPWR
CPU_FAN CHA_FAN
BATTERY
Super
I/O
ALC
887
RTL
8111F
ASM
1042
DIGI
+VRM
8Mb
BIOS
SB_PWR
22.6cm(8.9in)
LGA1155
Intel ®
H61
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module)
SATA_4 SATA3G_1
SATA_3 SATA3G_2
AUDIO
KBMS
LAN_USB12
USB34
HDMI
18.0cm(7.1in)
DVI_VGA
ASM
1061
4 2 3 1 6 5
7
2
10 11 12 1 13 14
8
9
• The layout illustrations in this user manual are for H61M-PLUS only.
• SATA_3/4 support SATA 6.0 GB/s in H61M PLUS and SATA 3.0 GB/s in H61M-A/
USB3 & H61M-A.
• USB34 supports USB 3.0 in H61M-PLUS & H61M-A/USB3 and USB 2.0 in H61M-A.
