ASUS M5A78L Series 2-11
Processor Frequency Multiplier [Auto]
Sets the processor frequency multiplier. Configuration options: [Auto] [x4.0 800MHz]
[x4.5 900MHz] [x5.0 1000MHz] [x5.5 1100MHz] ~ [x13.0 2600MHz] [x13.5 2700MHz] [x14.0
2800MHz] [x14.5 2900MHz] [x15.0 3000MHz]
CPU/NB Frequency [Auto]
Sets the CPU/Northbridge frequency. Configuration options: [Auto] [4.00x] [5.00x] [6.00x]
[7.00x] [8.00x] [9.00x] [10.00x]
CPU Over Voltage [Auto]
Sets the CPU over voltage. The valid value ranges vary depending on your CPU model. Use
<+> / <-> keys to adjust the ratio. Configuration options: [Auto]
VDDNB Over Voltage [Auto]
Sets the VDDNB over voltage. The valid value ranges vary depending on your CPU model.
Use <+> / <-> keys to adjust the ratio. Configuration options: [Auto]
If the system becomes unstable after changing the setting, set it back to [Auto] for safe
mode.
LoadLine Calibration [Auto]
Sets the LoadLine. Configuration options: [Auto] [0%] [3.225%] [6.450%] [9.675%] [12.90%] ~
[87.075%] [90.3%] [93.525%] [96.75%] [100%]
HT Link Speed [Auto]
Sets the HyperTransport link speed. Configuration options: [Auto] [200MHz] [400MHz]
[600MHz] [800MHZ] [1000MHz] [1200MHz] [1400MHz] [1600MHz] [1800MHz] [2000MHz]
HT Link Width [Auto]
Sets the HyperTransport link width. Configuration options: [Auto] [8 Bit] [16 Bit]
HT Over Voltage [Auto]
Sets the HT over voltage. The values range from 1.20000V to 1.38000V with a 0.01000V
increment. Use the <+> / <-> keys to adjust the value. Configuration options: [Auto]
[Max. = 1.38000V] [Min. = 1.20000V]
Memory Clock Mode [Auto]
Sets the memory clock mode. Configuration options: [Auto] [Manual]
PCIE Overclocking [Auto]
Configures the PCIE overclocking. Configuration options: [Auto] [Manual]
The following item only appears when you set PCIE Overclocking to [Manual].
PCIE Clock [100]
Sets the PCIE Clock. Configuration options: [Min.=100] [Max.=150]
