2-14 Chapter 2: Hardware information
Chapter 2
IRQ assignments for this motherboard
A B C D E F G H
Audio Controller – – – – – – shared –
EHCI Controller – – – – – – – shared
XHCI Controller shared – – – – – – –
SATA Controller – – – shared – – – –
PCIE x16_1 shared – – – – – – –
PCIE x16_2 shared – – – – – – –
PCIE x16_3 – shared – – – – – –
PCIE x1_1 – – shared – – – – –
PCIE x1_2 – – – shared – – – –
ASM1042 – – – shared – – – –
PCI Slot 1 – shared – – – – – –
PCI Slot 2 – – shared – – – – –
• In single VGA card mode, use the PCIe 3.0/2.0 x16_1 slot (blue) for a PCI Express x16
graphics card to get better performance.
• In CrossFireX™ or SLI™ mode, use the PCIe 3.0/2.0 x16_1 and PCIe 3.0/2.0 x16_2
slots for PCI Express x16 graphics cards to get better performance.
• We recommend that you provide sufficient power when running CrossFireX™ mode.
• Connect a chassis fan to the motherboard connector labeled CHA_FAN1/2/3 when
using multiple graphics cards for better thermal environment. See page 2-22 for
details.
• The PCIe 3.0 speed is supported by Intel ® 3rd generation Core TM processors.
