6-6 Chapter 6: RAID configuration
Clear disk data?
[Y] YES [N] Cancel
4. Press to create the RAID set. A pop-up window
appears.
5. Press to delete all data from the hard disk drives, or to continue creating
the RAID set without deleting the data on the disks.
The Array List windows appears.
You will lose all data on the drives if you clear the disk data!
6. The utility displays the created RAID set. Press to save your settings
and exit the utility.
[Ctrl-X]Exit [↑↓]Select [B]Set Boot [N]New Array [ENTER]Detail
NVIDIA RAID Utility Oct 5 2004
- Array List -
Boot Id Status Vendor Array Model Name
Yes 2 Healthy NVIDIA MIRROR XXX.XXG
[ESC] QUIT [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup
NVIDIA RAID Utility Oct 5 2004
- Define a New Array -
RAID Mode: Striping Striping Block: Optimal
Free Disks Array Disks
Loc Disk Model Name Loc Disk Model Name
[→] Add
[←] Del
1.0.M XXXXXXXXXXXXXXXXXX
1.1.M XXXXXXXXXXXXXXXXXX
