C h a p t e r 5 : B I O S s e t u p

5.4.5

Onboard Device

This menu shows the onboard device configuration settings. Select an item
then press to display a sub-menu with additional items, or show a
pop-up menu with the configuration options.

H/W Jumper of CSA LAN

Enabled

Onboard CSA LAN Boot ROM

[Disabled]

H/W Jumper of ONB LAN

Enabled

Onboard LAN Boot ROM

[Disabled]

Super I/O Device
SATA Configuration

Onboard Device

Select Menu

Item Specific Help

Enable/Disable Onboard
CSA LAN device boot ROM
support.

H/W Jumper of CSA LAN [Enabled]

This option tells whether the CSA LAN jumper labeled LAN_EN1 on the
motherboard is enabled or disabled. See section “2.6 Jumpers” for details.

Onboard CSA LAN Boot ROM [Disabled]

Allows you to enable or disable the onboard CSA LAN boot ROM.
Configuration options: [Disabled] [Enabled]

H/W Jumper of ONB LAN [Enabled]

This option tells whether the onboard LAN jumper labeled LAN_EN2 on the
motherboard is enabled or disabled. See section “2.6 Jumpers” for details.

Onboard LAN Boot ROM [Disabled]

Allows you to enable or disable the onboard LAN boot ROM.
Configuration options: [Disabled] [Enabled]
