Forum Lecture Seating Specifications
Page 3 of 5
2.7 WORKSURFACES
A. Tables are to be a 3-ply warp resistant construction with a core of 1-1/8” thick 45-50 lb. density particle
board, a 0.020” Kraft backer sheet, and a face material of 0.030” high-pressure laminate.
B. The edge detail is to be (select one edge detail from the list below)
1. 3mm PVC – 3mm x 1-1/4” PVC on all table edges that would be exposed after installation, with a 1/8”
radius on the top and bottom edges. The table corners are square with an overlap joint.
2. 3mm Hardwood – 3mm x 1-1/4” hardwood on all table edges that would be exposed after installation,
with 1/8” radius on the top and bottom edges, finished to match the architect’s sample. The table
corners are square with an overlap joint.
3. Bevel – 3/4” x 1-1/4” solid hardwood on all table edges that would be exposed after installation, with a
3/8” x 45 degree bevel detail along the top edge, finished to match the architect’s sample. The table
corners are mitered.
4. Chamfer – 3/4” x 1-1/4” solid hardwood on all table edges that would be exposed after installation, with
a 1/4” radius on the top edge blending into a 60 degree backcut chamfer edge detail, finished to match
the architect’s sample. The table corners are mitered.
5. Bullnose – 3/4” x 1-1/4” solid hardwood on all table edges that would be exposed after installation, with
a full 5/8” radius bullnose edge detail, finished to match the architect’s sample. The table corners are
mitered.
PART 3 – OPTIONS
3.1 WORKSURFACES
A. Tables are to be a 3-ply warp resistant construction with a core of 1-1/8” thick 45-50 lb. density particle
board, a 0.020” Kraft backer sheet, and a face material of veneer. The grain is to run the length of the
worksurface.
3.2 MODESTY PANELS
A. Straight modesty panels are to be a 3-ply warp resistant construction with a core of 5/8” thick 45-50 lb.
density particle board. The face surfaces are to be 0.030” high-pressure laminate. On laminates with a
wood grain, the grain is to run horizontally.
B. Straight modesty panels are to be a 3-ply warp resistant construction with a core of 3/4” thick 45-50 lb.
density particle board. The face surfaces are to be veneer; the grain is to run horizontally.
C. Curved modesty panels are to be 3/8” thick medium density fiberboard with a 1/2” thick x 1” wide birch
plywood strip affixed to the bottom edge. The face surfaces are to be 0.030” high pressure laminate. On
laminates with a wood grain, the grain is to run horizontally.
D. Curved modesty panels are to be 3/8” thick medium density fiberboard with a 1/2” thick x 1” wide birch
plywood strip affixed to the bottom edge. The face surfaces are to be veneer; the grain is to run
horizontally.
3.3 END PANELS
A. End panels are to be a 3-ply warp resistant construction with a core of 1-1/8” thick 45-50 lb. density particle
board. The face surfaces are to be 0.030” high-pressure laminate.
B. The vertical edges are to be self-edged.
3.4 ARMS
A. Arms shall be constructed of a steel bar with a self-skinned urethane overmolding. Arms shall be attached
to the chair with an 11 gauge cold-rolled steel bracket. The arms shall be attached to the bracket with (2)
M6 x 20mm bolts, and the bracket shall be attached to the chair frame with (3) 1/4-20 x 1-1/4 Grade 5
bolts.
3.5 TILT MECHANISM
A. Chair shall include a tilt mechanism with a tilt tension adjustment.
3.6 ELECTRICAL SYSTEM/DATA WIRE MANAGEMENT
A. Provide manufacturers standard modular electrical system for power distribution. All electrical modules
shall be manufactured from BX cable or liquid-tight BX cable, and shall have molded end connectors. The
modules shall connect to each other with a snap fitting designed so that they cannot be accidentally
