Starter Kit and User Manual for the HelloDevice 1300
29
Figure 5.11 index.html file for RS232 communication demo
(2) Build and upload web files in “SerialDemo” folder.
Follow the procedure described in section 5.1 with web files in “SerialDemo” folder instead of “FirstDemo”
folder to upload these web pages to the HelloDevice.
(3) After uploading has been completed, run the web browser to go to http://192.168.1.15/index.html page.
If the web page in figure 5.12 is not displayed, retry the (2) procedure.
(4) Test serial communication functionality of the HelloDevice.
You can try to test communication between your PC and HelloDevice in bi-directional manner. If you enter
characters on terminal applet of the HelloDevice web site, they are eventually echoed to the window of
HyperTerminal, or vice versa. In this demo, your PC functions both as a user device and as a user PC for remote
control of user device.
telnet
