1: Setup
2 000-10000-060-02-201311
Unpacking the HL-2000-CAL
► Procedure
1. Unpack your lamp assembly and power supply carefully. Although the lamp is rigidly mounted,
dropping this instrument can cause permanent damage.
2. Inspect the outside of the instrument and make sure that there is no damage. Do not use the
instrument if damage is present.
3. Use this instrument in a clean laboratory environment (see Operating Environment ).
Contents
Your HL-2000-CAL package should contain the following:
 HL-2000-CAL unit
 1 AC adapter for stabilizing power
 Power cord
 2 Lamp Calibration Reports; one for using the HL-2000-CAL with a bare fiber and one for using
the HL-2000-CAL with a CC-3 cosine-corrected irradiance probe
 1 CD that holds files for both lamp calibration reports
 1 Allen wrench for adjusting the inner barrel of the SMA connector
Connecting a Spectrometer to the HL-2000-CAL
► Procedure
Use the following procedure to connect your HL-2000-CAL unit to a spectrometer:
1. Loosen the set screw on the HL-2000-CAL's SMA connector
2. If using a bare fiber with the lamp:
Remove the inner barrel from the SMA connector (if using a bare fiber with the lamp). Screw this
connector barrel onto the end of your fiber. The connection should be tight. Insert the barrel/fiber
all the way into the HL-2000-CAL's SMA connector.
If using a fiber and cosine corrector with the lamp:
Remove the inner barrel from the SMA connector (if using a fiber and cosine corrector with the
lamp). Screw the CC-3 cosine corrector onto the end of the fiber. The connection should be tight.
Insert the CC-3/fiber all the way into the HL-2000-CAL's SMA connector, taking the place of the
SMA's inner barrel.
