XE-1-CAL Installation and Operation Instructions
2 008-00000-XE1-01-1209
Parts Included
The XE-1 package includes the following items:
 XE-1 Xenon Calibration Light Source
 12 VDC power supply
WARNING
The beam emerging from the light source contains UV radiation that can cause
serious eye injury upon direct contact with the eye. Never look directly into the
light source.
The SMA 905 Connector may get extremely hot during operation. After lamp
use, allow sufficient time to cool before handling.
Dangerous voltages are present, and there are no user-serviceable parts inside.
Never open the XE-1.
Additional Accessories
The following are additional accessories available from Ocean Optics that you may need, depending
on your system set-up:
 Spectrometer
 SMA-terminated optical fiber
 Ocean Optics software
Connecting the XE-1
Follow the steps below to set up your XE-1 for use.
► Procedure
1. Plug the 12 VDC power supply into a power outlet, then connect the barrel connector of the
power supply to the power input on the rear of the XE-1.
or
Alternately, you can use a 9-volt battery (not included) to power the XE-1. Open the battery
hatch of the XE-1 and install the 9-volt battery, and then proceed to Step 2.
2. Connect a fiber to the SMA 905 Connector on the XE-1. If your spectrometer does not have
an entrance slit, use a 50 m diameter (or smaller) fiber. Larger fibers and slits result in
reduced optical resolution.
