At a Glance
Size: 40 x 42 x 24 mm
Weight: 60 g
Wavelength range: 190-650 nm
Signal-to-noise ratio: >1500:1
Dynamic range: 4600:1
Photometric repeatability
(absorption)*:
Wavelength accuracy**: ± 0.13nm
*Photometric repeatability
measured at 260 nm. The
standard deviation of 10 individu-
al measurements is reported.
**Wavelength accuracy measured
at 546.08 nm using the HG-1
Mercury Argon Calibration
Source.
Small Size. Big Performance.
OneFocus Advantage
Configuration and Integration
By selecting the appropriate entrance slit for your STS-UV the resolution of the
measured spectrum can be optimized for your application. Choose a narrow slit for
light-rich applications where resolution is most important. For low-light applications,
select a larger entrance slit allowing more light into the spectrometer.
The STS-UV easily integrates into your small device or sits comfortably next to your
process line for quality control measurements. With several software control options,
including drivers that allow direct control of the spectrometer, the STS works with your
existing systems to help you get the valuable answers you need.
Ocean Optics offers a complete line of light sources and sampling accessories to
complement the STS-UV. Contact an OEM Sales Engineer today to get started.
The STS-UV is small, but its performance is comparable to spectrometers more than twice
its size. Using a unique optical design and a CMOS array detector, the STS-UV delivers a
high signal-to-noise ratio (>1500:1) and a wide dynamic range (4600:1), making it ideal
for measurements from low-concentration absorption to high intensity light and laser
characterization. Reliability was designed into the STS-UV, where a high thermal
stability and low baseline drift ensure your data stays accurate, even under changing
environmental conditions.
This spectrum shows the performance of the STS-UV for absorption measurements of
low concentration DNA solutions.
Absorption
Photometric
Repeatability
0.005 Abs
0.5 Abs
1.0 Abs
1.5 Abs
± 0.0001 Abs.
± 0.0002 Abs.
± 0.0005 Abs.
± 0.0008 Abs.
