LCN 4640 SERIES
AC
CE
SS
OR
IE
S
72MC
CYLINDERS
CYLINDER ONLY, 4642-3971
Standard, non-handed, cast iron cylinder.
CYLINDER ASSEMBLY, 4642-3071
Standard, non-handed, cast iron cylinder and mounting plate.
Includes; 4640-3454 Motor Clutch, 4640-3180 I/O Board
Assembly and 4640-3462 Controller.
CYLINDER ASSEMBLY, 4642-3071CS
Standard, non-handed, cast iron cylinder and mounting plate.
Includes; 4640-3454 Motor Clutch, 4640-3180 I/O Board
Assembly and 4640-3462 Controller. Same as a 4640-3071
assembly except on/off switch is concealed in endcap and no
hold open switch is included. (separate key switches
suggested)
COVERS
COVER, 4640-72MC
Standard, non-handed metal cover.
ARMS
REGULAR ARM, 4640-3077
Non-handed arm.
LONG ARM, 4640-3077L
Arm includes LONG ROD AND SHOE, 4640-79LR for deep
reveals.
ROD & SHOE, 9140-79
Rod for use with regular arm.
LONG ROD & SHOE, 9140-79LR
Long rod for use with long arm.
3077
3077L
79LR
79
3071
3971
3071CS
