ENGLISH
TABLE OF CONTENTS
THANKS FOR CHOOSING TOTO!
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and
function as a guiding principle. Congratulations on your choice.
Thanks for Choosing TOTO! ............................................................................. 2
Common Tools Needed ...................................................................................... 2
Included Parts ...................................................................................................... 2
Before Installation ................................................................................................ 3
Installation Procedure .......................................................................................3-5
Toilet Tank Fill Valve Instructions .....................................................................5-6
Flush Valve Servicing Instructions .......................................................................7
Warranty................................................................................................................ 8
Rough-In Dimensions ....................................................................................... 24
Replacement Parts ............................................................................................. 25
Check to make sure you have all these parts from the package:
COMMON TOOLS NEEDED
INCLUDED PARTS
• 10” adjustable wrench
• Carpenter’s Level
• Hacksaw
• Tape Measure
ADDITIONAL ITEMS (NOT SUPPLIED BY TOTO):
• Bowl Wax Ring
• Closet Flange Mounting Bolts
(usually 2 T-bolts, 2 metal washers and 2 nuts)
• Water Supply Line
(typically 1/2” compression to 7/8” ballcock)
• Toilet Seat (TOTO SoftClose recommended)
• Hand Pliers
• Flat Screwdriver
• Putty Knife
China Bowl Tank
a b
c d
e f
Tank Lid Tank to Bowl Gasket
Tank to Bowl Hardware
a. Bolts (metal) - 2 c. Washers (metal) - 4
b. Washers (rubber) - 2 d. Nuts (metal) - 4
Flange Caps (for Bowl)
e. Caps (plastic) - 2 b. Base (plastic) - 2
Care and Cleaning ...............................................................................................7
