Installation (continued)
Completing the Finished Wall
• After connecting the drain to the trap add the finished wall.
• Install tile or any finished wall material to provide a minimum gap of 2 mm (1/16”) for contraction
and expansion. Seal with silicone.
• Install the faucet trim according to the manufacturer’s instructions.
8
Tile In Flange Models
FBY1515, FBY1525 and FBY1715
Drop In
Silicone
Silicone
Finished Surface
•
Cut finished surface to desired dimensions.
•
Dry fit to the bathtub.
•
Temporarily mark on the bathtub the edge of the opening of the finished surface.
•
Remove the finished surface and apply silicone to the bathtub (underneath the finished surface
location).
•
Replace the finished surface and secure it.
•
Add and/or remove silicone as desired.
•
Make sure the finished surface is not supported by the bathtub and is secured per local codes.
Flat Rim Models
FBY1500, FBY1510,
FBY1550, FBY1700 and
FBY1800
Silicone
Ceramic/Stone/Tile
Water resistant
Gypsum board
(green board)
Bathtub Maintenance
WARNING: Do not use acidic or alkaline base products to clean the bathtub. Damage to
the enamel surface may occur.
• Be sure to clean the bathtub after each use. Dirt may stain the bathtub if left for long periods.
• Use neutral detergent, a soft cloth and a sponge. Follow only the installation instructions for your
particular model/installations.
• Before using the bathtub place a small amount of cold water into the bathtub. Then add hot wa-
ter. If the hot water is 80 ºC (176 ºF) and used directly the bathtub can become damaged.
• Avoid water containing sulfur. This will discolor the bathtub.
!
Under Mount Models
FBY1500, FBY1550, FBY1700 and
FBY1800
