R.S.V.P. Remote Switching Voltage Provider
Page 13
5 Technical Information
Since the R.S.V.P. is used with
Crown’s CT-10 series of amplifiers,
it is important to note the safety
features present at turn-on with the
CT-10 amplifiers.
All CT-10 series amplifiers have a
four-second turn-on delay. This
prevents dangerous turn-on tran-
sients. The CT-10 series also has
“soft-start” circuitry, which pro-
vides low inrush, and eliminates
the need for power sequencers.
6 Specifications
Line Voltage Requirements: Dual
range power supply operates at
100-120/200-240 V, 50/60 Hz.
Indicator: Enable LED (indicates
low-voltage supply operation).
Connectors: R.S.V.P. to Amplifier:
RJ-11 (telephone connector); Re-
mote Switch Closure: barrier block;
Slave/Aux In Port: RJ-11 (tele-
phone connector); Power Inlet: IEC
connector.
Recommended Maximum Wire
Lengths: R.S.V.P. to Amplifier: 30
feet (9.15 meters);
R.S.V.P. to Re-
mote Switch: 2000 feet (609.6
meters);
R.S.V.P. to Slave/Aux In:
2000 feet (609.6 meters); IQ Aux
Port to Slave/Aux In: 2000 feet
(609.6 meters).
Slave/Aux Control: DC: Minimum
Turn-On Voltage: 10VDC; Maxi-
mum Rated Input Voltage: 35VDC.
AC: Minimum Turn-On Voltage:
10VAC; Maximum Rated Input Volt-
age: 25VAC.
Amplifier Remote Signal: 24VDC (is
protected against short circuits).
Weight: 5 lb. 3 oz. (2.4 kg) shipping
weight.
Dimensions: 4 3 / 16 in. (10.6 cm) x 8
7 / 8 in. (22.55 cm) x 2.0 in. (5.17
cm).
