into the
PIP2
input adapter (see
Figure 3.7) and insert the
assembly into the
P.I.P.
opening in the back of the
amplifier.
4. Secure the
P.I.P.–EDCb
with
the two screws and lock
washers provided. (The lock
washers are important
because they bond the
P.I.P.
to
the chassis ground of the
amplifier.)
5. Connect input and output
wiring.
6. Plug in the amplifier and turn it
on. Adjust its level controls to a
desired setting.
Do not tamper with the circuitry.
Circuit changes made by unau-
thorized personnel, or unautho-
rized circuit modifications are not
allowed.
Remember:
Crown is not liable
for any damage resulting from
overdriving other components in
your sound system.
CAUTION: IF PHONE JACKS
ARE PROVIDED ON THE AM-
PLIFIER BACK PANEL, DO
NOT USE THEM AS INPUTS
WITH THIS
P.I.P.
INSTALLED.
The amplifier phone jacks are in
parallel with the
P.I.P.
outputs, so
they can be used to “daisy chain”
the inputs of several amplifiers. If
you do this, remember that the
signal feeding the other amplifi-
ers will be filtered and com-
pressed too.
Important:
If the amplifier is used
in either Bridged-Mono or Paral-
lel-Mono mode, you must turn
the Ch. 2 amplifier level control
off (fully counterclockwise). The
input and level control of Ch. 2
are not defeated in mono mode
so any signal applied to Ch. 2 will
beat against the signal in Ch. 1.
Refer to the amplifier
Reference
Manual
for more information
about Bridged-Mono or Parallel-
Mono modes of operation.
