Operation Manual page 6
Rack Specific
Weight: 184 lbs (84.5 kg)
Dimensions:
L x W x H with caster plate – 22 ½” X 23 ½” X 31 ¼” ( 57.2 cm X 59.7 cm X 79.4 cm )
L x W x H without caster plate – 22 ½” X 23 ½” X 25 7/8” (57.2 cm X 59.7 cm X 65.7 cm)
Rack-Specific Info:
• Colson 3 ½” polyurethane casters rated at 250 lbs (113 kg) per caster
• Polycarbonate, UV stabilized, “virtually unbreakable” front see-through door with 30x the impact resistance of acrylic
• Shock mounting using 8 neoprene rubber isolators rated at 90 lbs (41 kg) vertical and 30 lbs (13.6 kg) horizontal
with steel insert
• Captive pocket door system with a single-slam latch
• Removable caster plate with interlocking stacking system
Setup
Front View (23-1/2" x 31-1/4")
Top View (23-1/2" x 22-1/2")
Side View (22-1/2" x 31-1/4")
Bottom View (22-1/2" x 23-1/2")
