P.I.P.–BEQ
Page 15
4 Specifications
Note: All specifications are refer-
enced to a 0.775-V input signal.
Signal to Noise: Greater than 90
dB from 20 Hz to 20 kHz in Bypass
mode. Greater than 85 dB in EQ
mode.
Frequency Response: ±0.1 dB
from 20 Hz to 20 kHz in Bypass
mode. ±2 dB from the response
curves in Figure 3.1 through 3.6 in
EQ mode.
Harmonic Distortion (THD): Less
than 0.05% THD from 20 Hz to 20
kHz in Bypass mode with a 0 dBu
input signal. Less than 0.1% THD
from 20 Hz to 20 kHz in EQ mode
at 0 dBu.
Common Mode Rejection: Better
than 60 dB up to 1 kHz.
Crosstalk: Less than –60 dB from
20 Hz to 20 kHz.
Connectors: Solderless barrier
block or XLR connectors (depend-
ing on model) for both input and
daisy chain output.
Input Impedance: Nominally 50
kohms balanced; 25 kohms unbal-
anced.
Maximum Input Level: +20 dB.
Output Impedance: (daisy chain
output) Nominally 75 ohms bal-
anced.
Maximum Output Level: (daisy
chain output) +20 dB into a 600-
ohm load.
Nominal Gain: –6 dBV at 1 kHz
Dimensions: 6 3
⁄
8
x 1 7
⁄
8
x 3 7
⁄
8
in.
(16.2 x 4.8 x 9.8 cm).
Notes:
1. All resistor values are in ohms, ¼ W, 5% unless otherwise specified.
2. All capacitor values are in microfarads unless otherwise specified.
3. P1 pins 6, 8, 9, 10, 12-22 are not used.
