Factory Direct Hardware Schlage FE595PLY626JAZ User Manual
Page 8
1¹⁄₈"
(29 mm)
2³⁄₄"
(70 mm)
1¹⁄₂"
(38 mm)
1
"
(25 mm)
¹⁄₈
" (3 mm)
Strike cut-out specifications
Drill 4 holes
Mark 4 holes
1"
(25 mm)
(2)
(2)
Install for maximum security.
13
Prepare the Frame for the Strike
Place the reinforcement strike inside the strike hole and mark the 4 hole locations. Drill them as shown. If the strike
cut-out has not been prepared in the frame, see the “Strike cut-out specifications” box.
14
Install the Strike
