3
Check Backset
The backset is the distance from the edge of the door to the center of the hole through which the lock is installed.
This lock will fit either a 2C\,” backset or a 2C\v” backset. The bolt is preset to fit a 2C\,” backset. If your backset is not
2C\,”, you need to adjust your bolt by rotating it counterclockwise.
OR
2³⁄₈” (60 mm)
4
2³⁄₄” (70 mm)
2 ³⁄₄
4
Choose Faceplate
Choose the faceplate that most matches your existing door preparation. To use the round faceplate, first remove the
rectangular faceplate and back plate. Then attach the round faceplate.
OR
5
5
