Parts Breakdown
Aerator
Canopy
Handle canopy
Handle
Set screw
Handle knob
Index knob
O-ring
Metal index
Porcelain index
Handle wire
Valve body
Escutcheon
Cartridge
Sleeve
Spout
Trouble-Shooting
PROBLEM
Aerator leaks or has an inconsistent water flow pattern.
CAUSE
Aerator is dirty or improperly installed.
SOLUTION
Remove aerator, check for debris in the aerator screens, and confirm the rubber washer is properly installed.
Spout trim ring
Plastic protective sleeves
Set screw
Allen wrench
Canopy
Lock nut
