User Instructions:

Pull the handle forward to turn the water off. Push

it toward the rear to turn the water on.

Push the handle to the right for cooler water, to

the left for warmer water.

The angle of the water flow may be adjusted by

pivoting the spray former forward or backward.

Should the flow of water diminish, remove the

spray former and clean the aerator.

Replacement Parts

1 spout

97461000

2 spray former cpl.

97462000

3 spray former cpl. for bidet

97463000

4 handle

10092000

5 nut

97464000

6 cartridge cpl.

96339000

7 pop up rod

97158000

8 fixing set

13961000

9 round flow spray former

98610000

1

2,3

4

5

6

7

8

9
