1
English
Install the check valve in the elbow, with the arrow
pointing in the direction of the water flow.
Remove the plaster shield from the handshower
holder. Pull out on the handshower hose.
Screw the handshower holder escutcheon into place.
Install the elbow.
Install the spout escutcheon.
Firmly press the spout over the tee and diverter.
Tighten the set screw with the included mm �llen
wrench.
Do not overtighten the set screw
or the o-rings on the diverter will
deform, which will cause a leak.
Install the pull rod. The threaded end of the pull rod
must go into the hole in the pin.
3 mm
