10
English
4-Hole Trim Kits only
Remove the brass plug from the tee.
Lightly lubricate the diverter o�rings using white grease
(not included).
Press the diverter assembly firmly into the spout tee
until it is fully seated.
Turn the guide bushing so that the slot faces the rear
of the spout.
Install the spout escutcheon.
Press the spout over the spout tee. Install and tighten
the set screw with a mm �llen wrench.
Do not overtighten the set screw
or the o-rings on the sealing ring
will deform, which will cause a
leak.
Turn on the water and check all connections for leaks.
3 mm
