OPERATING INSTRUCTIONS
1. Deposit coins, tokens or debit card to
satisfy vend price display of idle dryer.
Each deposit decreases vend price until
display changes to show time purchased.
WARM
or LOW light illuminates.
2. Select drying cycle. Other cycle selec-
tions may be made now or later by pressing
the appropriate key (button).
3. Close the loading door. Press
START
and
the dryer will start. “Seconds” goes to .
“Minutes” is rounded up and will count
down each minute. The colon flashes on
and off indicating the timer is counting
down.
4. Clothes should be removed promptly after
the cycle is completed to prevent exces-
sive wrinkling.
Once started, the “timer” cannot be stopped. However, extra coins will be acknowledged by adding time to the
display. The dryer may be stopped by opening the loading door, which interrupts the drive motor and gas burners.
Close the loading door and push
START
to restart the dryer.
Cool-down time (owner programmable) is always part of the cycle time and is purchased by the customer. For
example, if cool-down time is 2 minutes, the last 2 minutes of the cycle will have no heat.
DESCRIPTION OF CONTROLS
Credit for coins deposited, dryer time and temperature are controlled by an electronic controller.
The large digital display shows vend price of an idle dryer, time purchased after coins are deposited, temperature,
and program information.
The three red indicator lights show the drying temperature selected. This selection may be made anytime.
The drying temperature will be displayed when the start switch and the switch for the selected temperature are
pressed at the same time.
All programmed data is protected from power interruption of any length and the customer’s individual cycle is
protected for up to 3 seconds. This is done without batteries.
The 3 temperature buttons and the start button become programming switches when the controller is in the
program mode as described on page 10.
EASY CARD MODELS
Some Dexter dryers are factory equipped with a card reader that is used with Dexter’s Easy Card debit card
system. The card reader signals the dryer control when money is debited from the user’s card account to satisfy
the price of the dry time. The dryer’s pricing and the Easy Card system pricing are completely independent of
each other and must be programmed separately and coordinated. Refer to the instructions that came with the
Easy Card system for complete information.
8
VEND PRICE MINUTES : SECONDS
PURCHASED
START
