Setting the Electronic Coin Acceptor Switches
1) The electronic coin acceptor has switches depending on the coins and country. See Table 1 ,
Table 2 , or Table 3 for available values of the left and right coin inputs for the available countries.
WARNING: TURN POWER OFF BEFORE AND LEAVE POWER OFF WHEN CHANGING
THE SWITCHES OF THE ELECTRONIC COIN ACCEPTOR.
2) Turn power back on and test coins to ensure proper operation.
Table 1
Acceptor P/N Country Left Coin Right Coin SWs 1-8 SWs 9-16
9021-014-002
Canada 25¢ ↓↓↑↑↑↑↑↓ ↓↑↑↑↑↑↑↓
Canada $1 ↑↑↓↓ ↑ ↑↑↓ ↓↑↑↑↑↑↑↓
Canada $2 ↑↑↑↑ ↓ ↓↓↓ ↓↑↑↑↑↑↑↓
Canada $1 + $2 ↑↑↓↓↓↓↓↓ ↓↑↑↑↑↑↑↓
Canada 25¢ $1 ↓↓↓↓ ↑ ↑↑↓ ↓↑↑↑↑↑↑↓
Canada 25¢ $1 + $2 ↓↓↓↓↓↓↓↓ ↓↑↑↑↑↑↑↓
Japan 100¥ ↓↓↑↑↑↑↑↓ ↑↓↑↑↑↑↑↓
Japan 500¥ ↑↑↓↓↑↓↓↓ ↑↓↑↑↑↑↑↓
Japan 100¥ 500¥ ↓↓↓↓↑↓↓↓ ↑↓↑↑↑↑↑↓
Taiwan 10NT ↓↓↑↑↑↑↑↓ ↑↑↓↑↑↑↑↓
Taiwan 50NT ↑↑↓↓↑↓↓↓ ↑↑↓↑↑↑↑↓
Taiwan 10NT 50NT ↓↓↓↓↑↓↓↓ ↑↑↓↑↑↑↑↓
Korea 500W ↓↓↑↑↑↑↑↓ ↑↑↑↓↑↑↑↓
Greenwald 118-1 Token ↑↑↑↑↑↑↑↓ ↑↑↑↑↓↑↑↓
Greenwald 118-5 Token ↑↑↑↑↑↑↑↓ ↑↑↑↑↑↓↑↓
U.S.A. 25¢ ↓↓↑↑↑↑↑↓ ↑↑↑↑↑↑↓↓
U.S.A. $1 ↑↑↓↓↑↑↑↓ ↑↑↑↑↑↑↓↓
U.S.A. 25¢ $1 ↓↓↓↓↑↑↑↓ ↑↑↑↑↑↑↓↓
Switches ↑=up/on, ↓=down/off
Note: Coins and tokens in the left coin column will result in one pulse to the left coin input.
Note: The $1, 500¥, 50NT, and $10 coins in the right coin column will result in one pulse to the right coin
input, while the $2 coin in the right coin column will result in two pulses to the right coin input.
Note: Acceptance of multiple coins per country and multiple tokens is allowed. Only the down/off setting
for each coin and token is required to accept that coin or token.
