- 20 -
cycle L.E.D. and programming L.E.D. will remain on, the cool down L.E.D. will illuminate, and the cool down
time will be shown on the 4-digit numeric display.
10) Press and release either the UP or DOWN touch pad switch on the dryer controller to change the cool down
time. Once either the UP or DOWN touch pad switch is pressed, the cool down L.E.D. and the cool down
time on the 4-digit numeric display will flash. If you press and hold down either the UP or DOWN touch pad
switch, you will increment (UP arrow) or decrement (DOWN arrow) through the cool down times available
(2 through 60 minutes if the controller has a red dot sticker or 2 through 15 minutes if the controller has no
red dot sticker). To not change the cool down time, do not press either the UP or DOWN touch pad
switch. Go to the next step.
11) Press and release the SELECT/ENTER touch pad switch on the dryer controller. Once the SELECT/ENTER
touch pad switch is pressed and released, the cool down L.E.D. will switch off, the dry cycle L.E.D. and
programming L.E.D. will remain on, the reversing L.E.D will illuminate, and either "rEv" (reversing mode) or
"nrEv" (non-reversing mode) will be shown on the 4-digit numeric display.
12) Press and release either the UP or DOWN touch pad switch on the dryer controller to change between
reversing and non-reversing operation. Once either of the UP or DOWN touch pad switch is pressed, the
reversing L.E.D. and the "rEv" (reversing mode) or the "nrEv" (non-reversing mode) shown on the 4-digit
numeric display will flash. To not change the reversing or non-reversing mode of operation, do not press
either the UP or DOWN touch pad switch. Go to the next step.
13) Press and release the SELECT/ENTER touch pad switch on the dryer controller. Once the SELECT/ENTER
touch pad switch is pressed and released, the reversing L.E.D. will switch off, the dry cycle L.E.D. and the
programming L.E.D. will remain on, and the 4-digit numeric display will change to “Prog”.
14) Press and release the STOP touch pad switch on the dryer controller to save the cycle program and escape
the programming mode. If you want to change the same dry cycle program again, press the
SELECT/ENTER touch pad switch and continue at step 6 of this procedure. If you want to modify another
dry cycle program, go to step 4 of this procedure and continue.
15) If you pressed the STOP touch pad switch to escape the programming mode, you may now start the dry
cycle by pressing the START touch pad switch.
PERMANENT REVERSING DRYER CONTROLLER PROGRAMMING
EXAMPLE
REQUIREMENTS: Dry a load, in reverse mode, with 50 minutes of actual heat at 195°F and three minutes of cool
down.
The following procedure will show you how to permanently modify the existing dry cycle 5 program for one
cycle of drying. It is based on the assumption that the factory defaults have not been permanently change. If
they have been changed, the steps of this procedure will be the same, but the values that are displayed will be
different. The amount of times that either the UP or DOWN touch pad switch of the dryer controller must be
pressed and released may also be different.
If you want the change to be temporary (for only one dry cycle), go to the “TEMPORARY REVERSING DRYER
CONTROLLER PROGRAMMING” section of this manual.
PROCEDURE:
1) After the load has been placed in the dryer, press and release the UP or DOWN touch pad switch on the
dryer controller until the L.E.D. for dry cycle 5 is illuminated.
2) Press and release the PROG touch pad switch on the dryer controller. The display of the dryer controller
will not change.
3) Immediately, press and release the UP touch pad switch on the dryer controller. The controller display will
change from “L0Ad” to “Prog”. You have now entered the permanent programming mode. The dry time
L.E.D. will remain on and the programming L.E.D. will illuminate.
4) Press and release the SELECT/ENTER touch pad switch once. The dry cycle 5 L.E.D. and the
programming L.E.D. will remain on, the dry time L.E.D. will illuminate, and the dryer controller will show
the number “25”.
