- 19 -
PERMANENT REVERSING DRYER CONTROLLER PROGRAMMING
The permanent programming mode will allow the change of the stored dry cycle settings in the dryer
controller until the operator physically changes them again. The factory default settings can be restored in the
dryer controller by pressing the default settings push-button on the back (component) side of the dryer controller
circuit board. It is labeled and located at the lower middle side of the printed circuit board, as you face the
component side of the board. It must be pressed and held down for at least three seconds.
To permanently change a dryer controller cycle, follow the procedure below. Things that are displayed on
the 4-digit numeric display will be in “quotation marks”. Touch pad switches on the dryer controller that
physically need to be pressed will be in CAPITAL AND BOLD LETTERS.
If, at any time, you want to escape the permanent programming mode while changing the settings, you can
press the STOP touch pad switch on the dryer controller if the 4-digit numeric display is not flashing. The
SELECT/ENTER touch pad switch on the dryer controller can be pressed and released to enter the flashing
value shown on the 4-digit numeric display and allow you to escape.
PROCEDURE
1) Make sure the dryer is not in a dry cycle. The 4-digit numeric display on the dryer controller will show “LOAd”
when the dryer is not in a dry cycle.
2) Press and release the PROG touch pad switch on the dryer controller.
3) Press and release the UP touch pad switch on the dryer controller. The programming L.E.D. will illuminate
and the 4-digit numeric display on the dryer controller will change to “Prog”.
4) Press and release either the UP or DOWN touch pad switch to choose the dry cycle you want to change
(dry cycle 1 through 5). The dry cycle L.E.D. will illuminate to indicate which dry cycle you are choosing. If
you press and hold down either the UP or DOWN touch pad switch, the controller will sequence through
the five dry cycles.
5) Press and release the SELECT/ENTER touch pad switch once you have chosen the dry cycle you want to
change. After you press the SELECT/ENTER touch pad switch, the dry time L.E.D. will illuminate, the dry
cycle L.E.D. and the programming L.E.D. will remain illuminated, and the total dry time will be displayed on
the 4-digit numeric display.
6) Press and release either the UP or DOWN touch pad switch on the dryer controller to change the total dry
time. Once either UP or DOWN touch pad switch is pressed, the dry time L.E.D. and the total dry time on
the 4-digit numeric display will flash. If you press and hold down either the UP or DOWN touch pad switch,
you will increment (UP arrow) or decrement (DOWN arrow) through the total dry times available (1 through
60 minutes). The dry time on the controller display includes the cool down time along with the heated
time. To not change the total dry time, do not press either the UP or DOWN touch pad switch. Go to the
next step.
7) Press and release the SELECT/ENTER touch pad switch of the dryer controller. Once the
SELECT/ENTER touch pad switch is pressed and released, the dry time L.E.D. will switch off, the dry
cycle L.E.D. and programming L.E.D. will remain on, the temperature L.E.D. will illuminate, and the drying
temperature will be shown on the 4-digit numeric display.
8) Press and release either the UP or DOWN touch pad switch of the dryer controller to change the drying
temperature. Each press and release of either the UP or DOWN touch pad switch will either increase or
decrease, respectively, the temperature by five degrees Fahrenheit or three degrees Celsius, depending on
how your dryer controller is set up. Once either the UP or DOWN touch pad switch is pressed, the
temperature L.E.D. and the drying temperature on the 4-digit numeric display will flash. If you press and hold
down either the UP or DOWN touch pad switch, you will increment (UP arrow) or decrement (DOWN
arrow) your way through the available drying temperatures (105° Fahrenheit or 41° Celsius, up to 195°
Fahrenheit or 90° Celsius). If you do not want to change the drying temperature, do not press either the
UP or DOWN touch pad switch. Go to the next step.
9) Press and release the SELECT/ENTER touch pad switch on the dryer controller. Once the
SELECT/ENTER touch pad switch is pressed and released, the temperature L.E.D. will switch off, the dry
