Dexter Laundry T-30X2 EXPRESS - 50 Hz Gas (On-Premise) - Manual (Page 24)

24
Maintenance Requiring Technical and Mechanical Skills:
Note: All procedures must be performed by a service engineer or competent person when the
dryer is not running.
(Disconnect power to dryer before beginning.)
QUARTERLY
1. Check tumbler shaft nuts, and, if lose, retighten to 150 lb. ft. (200 Nm).
2. Check belts for wear needing replacement to prevent reduced performance.
SEMI-ANNUALLY
1. Clean burners. Blow out burners, around primary air opening, and orifices with compressed air.
Run the dryer to assure operation and ignition and purge any dislodged lint from drying
chamber. Failure to do so can result in the risk of fire.
ANNUALLY
1. Check intermediate pulley bearings for wear.
2. Check and remove any lint accumulation from exhaust system. Lint accumulation causes
reduced drying performance, reduced ventilation of exhaust gases and an increased risk of fire.
SERVICE PARTS PART NUMBER
DRIVE BELT, MOTOR 9040-077-001
DRIVE BELT, TUMBLER 9040-073-009
LINT SCREEN FILTER 9555-057-002
For service and parts information contact your local Dexter agent. If a Dexter agent is not
available, contact Dexter Laundry, Inc. directly as listed below:
Mailing Address:
2211 West Grimes Avenue Phone: 1 + 641-472-5131 (USA)
Fairfield, IA 52556 Fax: 1 + 641-472-6336 (USA)
USA
Website: www.dexter.com/laundry/
