23

SERVICING THE DRYER

Note: A key with the markings “6324” is provided for service access to controller by a qualified
person. This key should be stored in a secure place away from the dryer. A different key is
required to open the coin box, if provided.

Routine Non-Technical Maintenance and Cleaning:

DAILY
1. Clean lint screens. Use soft brush if necessary. Failure to do so will slow drying, increase

temperatures throughout the dryer and increase the risk of fire. Dryer must not be operated
without lint screen in place. Without the lint screen in place, lint will accumulate in the
ductwork and flue exit reducing ventilation of exhaust gases.


2. Check lint screens for tears. Replace if necessary. Failure to replace a torn lint screen can

result in lint accumulation and reduced ventilation of exhaust gases.


MONTHLY
1. Removal of accumulated lint using a brush and vacuum cleaner. (Disconnect power to dryer

before beginning.)

a. Clean lint from lint screen compartments.

b. Remove lint accumulation from end bells of motors.

c. Vacuum the openings in the burner primary air openings.

d. Remove any lint from control compartment.

e. Remove lint and dirt accumulation from top of the dryer and all areas above, below, and

around the burners and burner housing. Failure to keep this portion of the dryer clean
can lead to a build up of lint creating a fire hazard.


2. Apply a few drops of light oil on top and bottom pivots of the loading door hinges to keep in

good working order.


3. Grease intermediate pulley bearings and shafts using pressure grease gun and lithium base

grease. Failure to do so can result in reduced product life.


QUARTERLY
1. Inspect door gasket for excessive wear.
