Dexter Laundry T-30X2 EXPRESS - 50 Hz Gas (On-Premise) - Manual (Page 2)

2
TABLE OF CONTENTS
DRYER DIMENSIONS (Figure 1) 3
UNCRATING 4
INSTALLATION CLEARANCE (Figure 2) 5
DRYER EXHAUST SYSTEM (Figure 3) 10
DRYER SHUTDOWN 10
TOUCH PAD LAYOUT (Figure 4) 11
DRYER DEFAULT SETTINGS 12
DRYER FAULT CODES 12
TOUCH PAD DESCRIPTION 13
OPERATING INSTRUCTIONS 15
PROGRAMMING INSTRUCTIONS 17
SERVICING DRYER 23
PREVENTATIVE MAINTENANCE 23
WARNINGS ABOUT USE AND OPERATION
It is ABSOLUTELY ESSENTIAL that the dryer be connected to a good earth connection. This
is not only for personal safety, but is necessary for proper operation.
KEEP SHIELDS, GUARDS AND COVERS IN PLACE. These safety devices are provided
to protect everyone from injury.
A DRYER SHOULD BE CONNECTED TO POWER FOR THREE (3) MINUTES before it
is operated or before a program change is made. Operation or program changes, which occur
during this “power up” period, are subject to loss in case of power interruption. After the initial
three minutes, all programmed data is protected from power interruptions of any length and the
customer’s individual cycle is protected up to 3 seconds. This is done without batteries.
LEAVE THE ELECTRICAL POWER TO THE DRYER ON AT ALL TIMES except when
necessary for service or other similar activities. The hour meter function adds only full hours to
its reading. If the power is shut off every night, any fraction of an hour of time that is on the
machine at that time will be lost. Turning the power off every night could also have some effect
on the long-term life of the memory after a number of years. Turning power off occasionally
won’t affect the unit.
THIS DRYER IS EQUIPPED WITH A MANUALLY RESETTABLE OVER-
TEMPERATURE THERMOSTAT located on the end of the burner housing above the gas
valve. Should the dryer cease to operate, refer to your “Service Procedure and Parts Data” book
for instructions.
CHECK THIS THERMOSTAT WHEN INSTALLING DRYER to assure it is not tripped.
Impacts, such as rough handling in shipment, may trip the thermostat. It may be reset by
inserting a wooden (nonconductive) pencil or dowel through the guide bushing in the cover.
